Two CAT6 cables and a fiber — from the basement to the attic

Two CAT6 cables and a fiber — from the basement to the attic

Since we first moved into this house — I’ve wanted to ceiling mount a Wi-Fi access point on the 2nd floor. But getting a network cable to the attic was challenging, so instead I opted for a Unifi UAP-AC-IW in the upstairs living room.

It’s time to do it right, but I’m not running just one. My earlier Wi-Fi mapping revealed poor 5 GHz coverage in the kid’s rooms, so I’m running two CAT6 cables — for two ceiling mounted Wi-Fi access points.

To have the option of running more CAT6 to rooms on the 2nd floor later — I’m including a 10 Gbit fiber as well 😎

And as my previous runs — no visible cables.

Read more →

Altibox fiber — straight into Ubiquiti EdgeRouter

Altibox fiber — straight into Ubiquiti EdgeRouter

Back in August I wrote about connecting my ISP (Altibox) fiber straight into the Mikrotik CCR1009. I’ve since decided not to include the CCR in my network stack, but instead use my EdgeRouter 4 as, well — the edge router, and VyOS to route the local networks.

So I moved the SFP module and fiber from the CCR — to the EdgeRouter 4 👇

Read more →

Altibox fiber — straight into Mikrotik CCR1009

Altibox fiber — straight into Mikrotik CCR1009

Ever since I got the fiber installed last year, the plan has been to drop the ISP box and plug it straight into my router. That’s why I had the fiber terminated in my patch panel.

I’ve been reluctant to do it, since messing with the internet needs to be done while the rest of the house is sleeping. And I was unsure what SFP module to use. I did buy the Ubiquiti UF-SM-1G-S pair, planning to use it with my EdgeRouter.

But I ended up using the SFP module that came with the ISP box, and my new MikroTik CCR1009.

The swap was super easy and only took a few minutes 😃

Read more →

Fiber in the patch panel

Fiber in the patch panel

I have two fiber cables in my patch panel — a single-mode simplex SC from my ISP, and a multi-mode duplex LC for 10 GbE network to my desktop computer.

Read more →
